injection mold polishing process decomposition

Release time: 2021-02-24 19:04:38  Hits: 40

The basic procedure of plastic mold polishing is to obtain high-quality polishing results, the most important thing is to have high-quality polishing tools and auxiliary products such as oilstone, sandpaper and diamond lapping paste.1410034.jpg

1. Fine polishing


Fine polishing mainly uses diamond abrasive paste. If the polishing cloth wheel is mixed with diamond abrasive powder or abrasive paste for polishing, the usual polishing order is 9μm (#1800) ~ 6μm (#3000) ~ 3μm (#8000). 9μm diamond abrasive paste and polishing cloth wheel can be used to remove hair-like wear marks left by #1200 and #1500 sandpaper. Then use sticky felt and diamond paste for polishing, the order is 1μm (#14000) ~ 1/2μm (#60000) ~ 1/4μm (#100000). The polishing process with accuracy requirements above 1μm (including 1μm) can be carried out in a clean polishing room in the mold processing workshop. For more precise polishing, an absolutely clean space is necessary. Dust, smoke, dandruff and saliva can all scrap the high-precision polished surface obtained after hours of work.


2. Rough polishing


After milling, electric spark, grinding and other processes, the surface can be polished with a rotating surface polisher or ultrasonic grinder with a speed of 35 000-40 000 rpm. The commonly used method is to remove the white electric spark layer with wheels with diameter Φ3mm and WA # 400. Then there is manual whetstone grinding, and the strips of whetstone are added with kerosene as a lubricant or coolant. The general order of use is #180 ~ #240 ~ #320 ~ #400 ~ #600 ~ #800 ~ #1000. Many mold manufacturers choose to start with #400 in order to save time.


3. Semi-precision polishing


Semi-finish polishing mainly uses sandpaper and kerosene. The number of sandpaper is: #400 ~ #600 ~ #800 ~ #1000 ~ #1200 ~ #1500. In fact, #1500 sandpaper only uses die steel suitable for hardening (above 52HRC), not pre-hardened steel, because it may cause burns on the surface of pre-hardened steel.


4. Fine polishing


Use abrasive paste for fine polishing, 8000, 10000 will reach the mirror surface.
